The different types of magnets which have industrial uses
Bonded
Neodymium magnets are made of the strong Nd-Fe-B material blended
into an epoxy binder. The mix contains nearly 97% magnet material and 3% epoxy.
The manufacturing process includes the process of combining Nd-Fe-B powder with
an epoxy binder and squeezing the mixture. Hence, the material is assembled by
compression bonding, the dimensions usually differ slightly.
Features
·
Bonded neodymium-iron-boron (NdFeB) magnets are powerful
magnets that are generally used for different applications.
·
Epoxy coating is one of the most commonly used
for bonded NdFeB magnets,
·
Electroless nickel plating is generally used to avert
disintegration.
·
Isotropic bonded magnetic
core material like NdFeB material can be easily magnetized in any
direction, or with many poles.
·
Bonded Nd-Fe-B material is usually isotropic, so
it can be easily magnetized through any direction, including multi-polar
arrangements. Since the material is in an epoxy binder, it can be easily
manufactured or machined on a mill or lathe. Nonetheless, the material will not
support a thread, so holes cannot be tapped.
·
Bonded Nd-Fe-B material is generally used to considerably
decrease the size of designs that generally used ceramic magnet materials. Vital
size reductions can be achieved since the material is nearly three times tougher
than ceramic magnet material.
·
Additionally, as the material is isotropic, it
can be easily magnetized multi-polar, like the N-S-N-S (North-South- North-South)
pattern on the outer diameter of a ring.
Magnetic bead separation is a fast, effective, clean process that is
generally used to restore filtration, centrifugation, and separation
techniques. Magnetic beads and pieces are usually functionalized with antigens,
antibodies, catalyzers, proteins, or nucleic acids, allowing action on cells,
bacteria, viruses, and different biological entities. These complexes are then parted
from a compact matrix with a magnetic separation frame. The result of all these
processes will be an enriched and concentrated sample of the target entity.
Permanent Magnets
A permanent magnet is an object
usually made from a material that is magnetized and forms its own continuous
magnetic field. A daily example can be a refrigerator magnet that is used to
hold notes on a refrigerator door. Materials that can be easily magnetized and are
strongly attracted to a magnet are called ferromagnetic. These usually include
elements such as iron, nickel, cobalt, and their alloys, some alloys of
rare-earth metals, and some naturally occurring minerals like a lodestone.
Types of Permanent magnets
·
Magnetic metallic elements
·
Composites
·
Rare-earth magnets
·
Single-molecule magnets (SMMs)
·
Single-chain magnets (SCMs)
·
Nano-structured magnets
·
Earth free permanent magnets
